How much does a StruXure pergola cost?

StruXure only sells through local dealers, who design each system and quote after a site visit, and its own cost page says it can’t give a price before that. The published estimates we found, from HomeGuide and the cost site ThePricer, both put an installed Pergola X at $150 to $200 a square foot. Here is what that means at common sizes.

Treat these as a starting point, not a quote. ThePricer’s regional figures run from about $150 a square foot in the Midwest to about $200 in Northeast cities, and very large systems can come in a little lower per foot. A rival seller, The Luxury Pergola, puts a 12×16 at about $45,000 installed, above the range.

StruXure’s one product with a listed price is the Cabana X, a 10×10 motorized louvered unit you put up yourself. Patio Pelican lists it at $8,997, or $9,497 with lights, delivered but not installed. A dealer-installed 10×10 Pergola X is estimated at $15,000 to $20,000.

They aren’t the same product, so the gap isn’t all labor. But it gives you a feel for what a dealer adds: design, footings, wiring, the permit and two days of installation per zone. If a 10×10 fits your space and you’re handy, the Cabana X is the cheapest way to own a StruXure.

Size comes first. A single Pergola X zone has a maximum span, so a big patio means two or more zones joined together, each with its own posts and motor. Attaching it to the house, uneven ground and long runs for the electrics add labor.

Then come the extras, which StruXure doesn’t price either. ThePricer’s estimates are the only published figures: motorized screens $5,000 to $12,000, heaters $3,000 to $4,000, lighting $2,000 to $3,500, and rain and wind sensors $1,200 to $1,800. It also puts permits at $250 to $700 and stamped engineering at $900 to $1,400.

You are paying for a finished job as much as a roof. The dealer designs the system to your space, handles the permit, pours or sets the footings, runs the power and installs it, which StruXure says takes about two days per zone.

The warranty is longer than any kit’s: 15 years on the posts, beams, louvers and gutters, five on the motor and controls, and lifetime cover on the system against manufacturing defects. It transfers free to the next owner of your house. You must register within 30 days of installation, claims go through your dealer, and from the second year you pay for shipping and for removing and refitting the part.

The Pergola X also has an independent ICC-ES evaluation report, which can make a permit easier where your building department wants engineering. It doesn’t cover high-seismic areas, special wind regions or South Florida’s hurricane zone, so ask your dealer how approval works if you live in one.

If your patio fits a standard size, a motorized louvered kit gives you the same idea, louvers that open and close at the press of a button, for a fraction of the price. At 10×13 the kits below cost about $3,300 to $15,000, against an estimated $19,500 to $26,000 for a StruXure.

Bigger spaces narrow the gap but don’t close it. At 13×19, the largest size most of these kits come in, a StruXure is estimated at $37,050 to $49,400 installed, while the kits below cost about $12,600 to $22,000.

A kit price is the kit at your curb. Anchoring, a concrete pad if you have none, an outdoor outlet for the motor and paid assembly come on top, and our pergola cost guide adds them up. Even with all of it, a motorized kit usually lands well under a StruXure of the same size.

Get a StruXure quote if your space is bigger than about 13×19 or an odd shape, it will attach to the house, or your building department wants engineering. It also suits you if you want one company to design, permit and install it and stand behind it for years.

Buy a kit if a standard size fits, you’re happy to assemble it or hire someone, and you would rather keep the difference. PergoLux and Hansø make the closest kits to a StruXure, with app control and ten years on the frame; Hansø’s Apex goes up to 13×26.

Get more than one. Prices vary by dealer and region, and the other dealer-installed brands are worth a second quote: HomeGuide puts Azenco at about $80 to $120 a square foot and Equinox at about $65 to $100. Ask each dealer to itemize the zones, motor, screens, lights, footings, electrical work and permit, so you can compare like with like.

Ask who registers the warranty within the 30 days, how long the dealer has sold StruXure, and what happens to your deposit if the schedule slips. Lead times vary by dealer, so get the installation date in writing.
